Khoom Description
USB Connector Txhaj Tshuaj Moulding Tshuab, haum rau ntau yam thermoplastics: PC / ABS, PBT, PC, PS, PVCPP, PU, PA, POM, PMMA, PET, PPO, PPS, ABSPE, LCP, acrylic, melamine, 372, nylon , polypropylene, polystyrene thiab lwm yam.
Khoom nta
Saib cov ntaub ntawv hauv qab no, koj tuaj yeem kawm paub ntxiv txog peb USB Connector Txhaj Tshuaj Moulding Tshuab,
|
JY{0}}ST
|
||||
|
Ntsia Hlau Diameter
|
mm
|
Φ32
|
Φ36
|
Φ40
|
|
Theoretical Txhaj Volume
|
cm3 ua
|
128.9
|
162.7
|
226
|
|
Txhaj hnyav
|
g
|
121.5
|
153.8
|
201
|
|
Max.Injection Siab
|
Mpa
|
201
|
158.85
|
128.6
|
|
Txhaj tus nqi
|
cm³/s
|
70.7
|
89.5
|
110.5
|
|
Txhaj Ceev
|
mm/s
|
88
|
||
|
Txhaj Tshuaj Stroke
|
mm
|
160
|
||
|
Screw ceev tig
|
r.p.m
|
0-200
|
||
|
NO.of Temperaturecontrol
|
|
4
|
||
|
Nozzie tawm ntawm Platens
|
mm
|
Ntau dua lossis sib npaug li 45
|
||
|
Clamping Force
|
KN (tf)
|
539(55)
|
||
|
Clamping Stroke
|
mm
|
200
|
||
|
Min. Pwm Thickness
|
mm
|
180/280
|
||
|
Max. Qhib
|
mm
|
380/480
|
||
|
Qhov nrug nruab nrab ntawm Tie Bas (L * W)
|
mm
|
470*280
|
||
|
Mould Loj (L * W)
|
mm
|
500*450
|
||
|
Platen Loj (L * W)
|
mm
|
600*450
|
||
|
Ejector nrug
|
mm
|
35
|
||
|
Ejector Force
|
KN (tf)
|
172(1.75)
|
||
|
System Siab
|
Mpa
|
13.7
|
||
|
Roj Tank Muaj Peev Xwm
|
L
|
175
|
||
|
Hluav taws xob
|
KW (HP)
|
7.5(10)
|
||
|
Rhaub Fais Fab
|
KW
|
5.3
|
||
|
Tshuab Dimensions (L * W * H)
|
m
|
1.67*1.1*2.5*2.46/3.2
|
||
|
Tshuab hnyav
|
ua tf
|
2.1
|
||
Qhov peb siv hauv kev tsim khoom
XCX harness khoom tsim los ntawm 2017, yav dhau los 7 xyoo txoj kev loj hlob, peb tau tsim ib tug muaj zog nyob rau hauv cov teb chaws Europe, lub tebchaws United States, thiab Southeast Asia. Peb cov thev naus laus zis tsim khoom txuas ntxiv mus, uas tau tsav los ntawm cov neeg siv khoom tshwj xeeb. Peb qhov kev cog lus yog los muab cov khoom lag luam zoo thiab cov neeg siv khoom txaus siab tshwj xeeb.
yas txhaj tshuaj tshuab
wir uae tshuab stripping
hlau soldering tshuab
hlau crimping tshuab
Peb Daim Ntawv Pov Thawj
Tag nrho peb USB Connector Txhaj Moulding Tshuab muaj CE
FAQ
Q: Koj puas yog cov chaw tsim khoom?
A: Yog lawm, peb tau muab cov khoom tshwj xeeb hauv cov ntaub ntawv no rau 15 xyoo.
Q: Koj ntim cov khoom no li cas?
A: Feem ntau ntim nrog rooj ntoo.
Q: Puas yog customizable?
A: Kom paub meej, peb yuav teeb tsa raws li koj qhov ntau thiab tsawg.
Q: Yuav ua li cas txog koj qhov kev pab cuam tom qab muag?
A: 24H kev txhawb nqa hauv xov tooj, email lossis skype.
Q: Koj lub sijhawm ua haujlwm yog dab tsi?
A: 1-3hnub rau cov qauv hauv Tshuag, 10-30hnub rau cov qauv kev cai.
Q: Koj puas muaj CE?
A: YOG
